Name: Compact Bidirectional Energy Storage Solar Inverter with Ultra-Wide MPPT Range 30Vdc-80Vdc and Pure Sine Wave Output
Brand: test
Price: 180 USD
Availability: InStock

Home > Products > Energy >

Compact Bidirectional Energy Storage Solar Inverter with Ultra-Wide MPPT Range 30Vdc-80Vdc and Pure Sine Wave Output

Bidirectional Energy Storage Solar Inverter

Ultra-Wide MPPT Range DC/DC Inverter

Pure Sine Wave Output Energy Storage Inverter

Place of Origin:

Changsha, CN

Brand Name:

Ecer

Certification:

Request A Quote

Compact Bidirectional Energy Storage Solar Inverter with Ultra-Wide MPPT Range 30Vdc-80Vdc and Pure Sine Wave Output

Product Details

Circuit Topologies:

Push-pull Type

Output Power:

>1000W

Max PV Input Power:

1500W-5000W

MPPT Voltage Range:

30Vdc-450Vdc

Rated Voltage:

180Vdc-240Vdc

Max PV Voltage:

300Vdc-500Vdc

Max PV Current:

13A-18A

MPPT Channels:

1 Routed

Battery Type:

Lead-acid/Lithium

Rated Battery Voltage:

12Vdc-24Vdc

Battery Voltage Range:

10.5-30Vdc

Max Charging Current:

60A-120A

Output Voltage Accuracy:

±2%

Output Frequency Accuracy:

±1%

Power Factor:

>0.98

Highlight:

Bidirectional Energy Storage Solar Inverter

Ultra-Wide MPPT Range DC/DC Inverter

Pure Sine Wave Output Energy Storage Inverter

Payment & Shipping Terms

Minimum Order Quantity

Price

180

Related Products

Contact Now

Product Description

Compact Mobile Energy Storage Solar Inverter for Home Applications

Reliable Wall-Mounted Home Battery Storage System

High-frequency design with high power density, compact size, and high efficiency. Bidirectional storage design enables bidirectional power control, utilizing both solar and mains power for charging. Features ultra-wide MPPT range supporting 30Vdc to 80Vdc.

Technical Specifications

Parameter	1000W	1300W	1800W	1800w	2300W	3300W
Rated Power	1000W	1300W	1800W	1800w	2300W	3300W
Max PV Input Power	1500W	2000W	2500W	2500W	3000W	5000W
MPPT Tracking Voltage Range	30Vdc-240Vdc		40Vdc-350Vdc		40Vdc-450Vdc
Rated Voltage	180Vdc			240Vdc
Max PV Input Voltage (VOC)	300Vdc		400Vdc		500Vdc
Max PV Input Current	13A	15A	18A	-	-	-
MPPT Tracking Channels	1 Routed
Battery Type	Lead-acid Battery/Lithium Battery
Rated Battery Voltage	12Vdc			24Vdc
Battery Voltage Range	10.5-15Vdc (default)			21-30Vdc (default)
Max PV Charging Current	60A	80A	100A	60A	80A	120A
Max AC Charging Current	40A	50A	65A	35A	50A	80A
Max Charging Current	60A	80A	100A	60A	80A	120A
Rated Input Voltage	230V (220V or 240V can be set)
Mains Input Voltage Range	165Vac-280Vac/120Vac-280Vac (can be set)
Rated Input Frequency	50Hz/60Hz
Input Frequency Range	45Hz-55Hz (50Hz), 55Hz-65Hz (60Hz)
Rated Output Voltage	230V (220V or 240V can be set)
Output Voltage Accuracy	±2%
Output Frequency Accuracy	±1%
Output Wave	Pure Sine Wave
Output Current	4.3A	5.6A	7.8A	7.8A	10A	14.3A
Power Factor	>0.98 (Rated Power)
No Load Loss	1% Rated Power (Typical value)
MPPT Tracking Efficiency	≥99.9%
Transfer Time	10ms (Typical value)
Display	LCD+LED
Cooling Method	Cooling fan in intelligent control
Communication	RS485/Mobile APP (WIFI Monitoring or GPRS monitoring) (Optional)
Protection Degree	IP20
Anti-islanding Protection	≤2S

Physical Dimensions & Weight

Model	Product Size (L×W×H mm)	Package Size (L×W×H mm)	Net Weight (kg)	Gross Weight (kg)
1000W	265×231×91	340×286×156	3	3.5
1300W	285×250×91	360×305×156	3.6	4.5
1800W	310×250×91	385×305×156	4	5
1800w	285×250×91	360×305×156	3.7	4.6
2300W	325×275×102	400×330×167	3.9	4.8
3300W	-	-	5.5	6.5

Advanced Features

Supports configurable modes (grid-connected, off-grid, hybrid)
Allows setting grid-connected current

Provides output and charging priority settings
Features BMS communication for lithium batteries

Supports battery-free operation mode

Frequently Asked Questions

Why should you choose us?

Extensive electrical equipment experience, professional sales & R&D team, qualified products with competitive pricing, timely delivery, and sincere service.

How is your after-sale service?

We offer 1-2 years warranty and 1% spare parts free. We repair or replace PCBs as needed.

What kind of certification do you have?

ISO9001, ISO14001, CE, ROHS, UL, etc. All products pass various tests per different countries' requirements.

What is the delivery time?

Standard products delivered within 15 days.

Can I have a sample order?

Yes, sample orders are welcome to test quality.
