Kiosk Android Tablet for Office Meeting Rooms & Digital Signage
Product Overview
Professional kiosk Android tablets available in 10-inch, 13.3-inch, and 14-inch configurations. Designed for office meeting room smart booking systems, digital signage, and various industrial applications. Features 4G LTE connectivity and runs on Android 12/11 operating systems.
10-inch Model Specifications
| Component | Specifications |
|---|
| CPU | Multiple processor options: T618 Cortex-A75, MT8768, MT8766, MT8765, MT8321, SC9863, SC9832E, SC7731E, MT8168, MT8167, RK3368H, RK3326 |
| Operating System | Android 12 |
| Screen | 10.1" 1280 x 800 IPS G+P, 13" 2160x1440 IPS, 14" 1920x1080 IPS |
| RAM | 1GB/2GB/3GB/4GB/6GB |
| Storage | 8GB/16GB/32GB/64GB |
| Connectivity | WiFi 802.11 ac/a/b/g/n; Bluetooth 4.0/5.0; 4G LTE FDD/TDD; 3G; 2G |
| Camera | Front 0.3/2MP, Rear 2/5MP |
| Additional Features | GPS, FM, G-sensor, micro USB |
| Dimensions | 247.6 x 155.2 x 9.3mm |
| Battery | 5000mAh |
13-inch Model Specifications
| Component | Specifications |
|---|
| Display | 13 inch 2160x1440 2K IPS screen with narrow bezel, anti-glare protection |
| CPU | MTK8183 Octa core (A53*4 + A73*4), 2.0GHz |
| GPU | Arm Mali-G72 |
| RAM | 4GB/6GB/8GB |
| Storage | 64GB/128GB/256GB |
| Operating System | Android 12 |
| Camera | Front: 8MP, Rear: 8MP with flashlight |
| Battery | 3.8V/7500mAh |
| I/O Ports | Type C, Reset Hole, Micro-SD Card Slot |
| Connectivity | Dual Wi-Fi (2.4G+5G), BT5.0, External 3G Data Optional |
| Construction | Full metal body, ultra thin 8.9mm, four box speakers |
14-inch Model Specifications
| Type | Details | Descriptions |
|---|
| Product Form | Default Orientation | Metal construction |
| Dimensions | Size | 339.3 x 213.7 x 9.9mm |
| LCD | Screen Size & Resolution | 14.1" 1366x768 IPS or 1920x1080 IPS |
| Touch Panel | Touch Module | G+G |
| Battery | Type & Capacity | Lithium-ion polymer, 3.7V/6000mAh (up to 10000mAh), ~5 hours endurance |
| CPU | Type | SC9863A Cortex A55 Octa-core 1.6Ghz / MTK8168 / MTK6762 |
| GPU | Type | IMG8322 |
| RAM | Capacity | 2/3/4GB |
| Storage | Capacity | 16/32/64GB |
| Camera | Front & Rear | Front: 2MP, Rear: 5MP with flash light |
| Connectivity | Wireless & Ports | 2G/3G/4G, WiFi 802.11 2.4GHz, BT4.2, FM, GPS, Type-C, 3.5mm jack, SIM, TF card |
| Operating System | Version | Android 11 with GMS, English language |
Product Images
Packaging & Shipping
Company Profile
Shenzhen Pretech Industrial Co., Ltd., founded in 2014, specializes in research and development of consumer electronics. We deliver high-quality Android, Linux, and Windows based terminals including tablet PCs, smartphones, and notebooks. Our professional R&D, sales, and service teams have extensive experience in large ODM and OEM custom projects.
We develop smart terminals with LTE, Wi-Fi, Bluetooth, Zigbee, ZWave, NFC, 3D TOF camera, and various interfaces for applications in smart home automation, security, in-vehicle infotainment, healthcare, education, advertising, and payment systems. All products are CE, FCC, ROHS & Reach certified.
Frequently Asked Questions
Q1: Can you support custom tablet design?
A1: Yes, we provide custom ID and MD design based on your reference and usage scenario requirements.
Q2: Do you support software development?
A2: We handle system and driver level development. Application-level development is typically handled by clients or third-party developers.
Q3: Which operating systems do you support?
A3: We support custom OS development based on Android, Windows, Linux, and Ubuntu operating systems.
Q4: Can you modify hardware features?
A4: Yes, we can remove batteries or cameras, ship without cases, and add interfaces like POE, USB Type C, DC IN, and HDMI.
Q5: Do you provide SDK services?
A5: Yes, we provide SDK (software development kit) services for customers.
Q6: What is your experience with smart home projects?
A6: We have extensive experience with smart home IoT projects including integration with Tuya, Google Assistant, Alexa, Zigbee, Z-wave, and LoRa technologies.
Q7: Can you customize accessories?
A7: Yes, we support custom smart covers, docking stations, charging docks, magnetic clips, wall mounts, and stylus pens.
Q8: Do you provide prototype samples?
A8: Yes, we provide prototype samples before bulk orders upon receiving detailed requirements.
Q9: What is the typical development timeline?
A9: Normally 3-5 months, depending on project complexity. Contact us with your requirements for a specific timeline.
Q10: How is development cost calculated?
A10: Development costs include tooling design and PCBA development/hardware tuning. Costs vary by project requirements.
Q11: Can we sign an NDA?
A11: Yes, we can sign mutual non-disclosure agreements.
Q12: How is intellectual property handled?
A12: Intellectual property ownership is determined by agreement between clients and Pretech during joint development.
Q13: What is your warranty policy?
A13: Standard 1-year warranty with options for 2-year or extended warranties available upon request.
