Name: Hybrid Solar Inverter with Ultra-wide MPPT Range 30Vdc-80Vdc and Bidirectional Energy Storage for Pure Sine Wave Output
Brand: test
Price: 180 USD
Availability: InStock

Home > Products > Energy >

Hybrid Solar Inverter with Ultra-wide MPPT Range 30Vdc-80Vdc and Bidirectional Energy Storage for Pure Sine Wave Output

Ultra-wide MPPT range Hybrid Solar Inverter

Bidirectional energy storage Hybrid Solar Inverter

Pure sine wave output Hybrid Solar Inverter

Place of Origin:

Changsha, CN

Brand Name:

Ecer

Certification:

Request A Quote

Hybrid Solar Inverter with Ultra-wide MPPT Range 30Vdc-80Vdc and Bidirectional Energy Storage for Pure Sine Wave Output

Product Details

Output Power:

>1000W

Circuit Topologies:

Push-pull Type

Rated Power:

1000W| 1300W| 1800W| 1800w| 2300W| 3300W

Max PV Input Power:

1500W| 2000W| 2500W| 2500W| 3000W| 5000W

MPPT Tracking Voltage Range:

30Vdc-240Vdc| 40Vdc-350Vdc| 40Vdc-450Vdc

Rated Voltage:

180Vdc| 240Vdc

Max PV Input Voltage:

300Vdc| 400Vdc| 500Vdc

Max PV Input Current:

13A| 15A| 18A

MPPT Tracking Channels:

1 Routed

Battery Type:

Lead-acid Battery/Lithium Battery

Rated Battery Voltage:

12Vdc| 24Vdc

Battery Voltage Range:

10.5-15Vdc(default)| 21-30Vdc(default)

Max PV Charging Current:

60A| 80A| 100A| 60A| 80A| 120A

Max AC Charging Current:

40A| 50A| 65A| 35A| 50A| 80A

Output Wave:

Pure Sine Wave

Highlight:

Ultra-wide MPPT range Hybrid Solar Inverter

Bidirectional energy storage Hybrid Solar Inverter

Pure sine wave output Hybrid Solar Inverter

Payment & Shipping Terms

Minimum Order Quantity

Price

180

Related Products

Contact Now

Product Description

Hybrid Solar Inverter with Mobile Energy Storage for Domestic Use

Reliable Wall-Mounted Home Battery Storage System

This high-frequency design hybrid solar inverter features exceptional power density in a compact size with maximum efficiency. The bidirectional energy storage system enables charging from both solar panels and mains electricity, while the ultra-wide MPPT range supports 30Vdc to 80Vdc for optimal solar energy harvesting.

Key Features

High-frequency design with compact size and high efficiency
Bidirectional energy storage for solar and mains electricity charging
Ultra-wide MPPT range (30Vdc-80Vdc)
Configurable operation modes: grid-connected, off-grid, hybrid
Grid-connected current settings
Output and charging priority settings
BMS communication for lithium batteries
Battery-free operation support
LCD display with LED indicators
RS485/Mobile APP communication (WIFI or GPRS monitoring optional)

Technical Specifications

Parameter	1000W	1300W	1800W	1800w	2300W	3300W
Rated Power	1000W	1300W	1800W	1800w	2300W	3300W
Max PV Input Power	1500W	2000W	2500W	2500W	3000W	5000W
MPPT Tracking Voltage Range	30Vdc-240Vdc		40Vdc-350Vdc		40Vdc-450Vdc
Rated Voltage	180Vdc			240Vdc
Max PV Input Voltage (VOC)	300Vdc		400Vdc		500Vdc
Max PV Input Current	13A	15A	18A	-	-	-
Battery Type	Lead-acid Battery/Lithium Battery (Customizable charge/discharge parameters)
Rated Battery Voltage	12Vdc			24Vdc
Max PV Charging Current	60A	80A	100A	60A	80A	120A
Max AC Charging Current	40A	50A	65A	35A	50A	80A
Rated Output Current	4.3A	5.6A	7.8A	7.8A	10A	14.3A
Output Wave	Pure Sine Wave
MPPT Tracking Efficiency	≥99.9%
Transfer Time	10ms (Typical value)
Protection Degree	IP20

Product Images

Frequently Asked Questions

Why choose us?

Years of expertise in electrical equipment, professional sales and R&D teams, competitive pricing, timely delivery, and sincere service.

How is your after-sale service?

1-2 years warranty, 1% spare parts free. We repair PCBs or provide new ones.

What certifications do you have?

ISO9001, ISO14001, CE, ROHS, UL, etc. All products pass various labor tests per country requirements.

Delivery time:

Standard products delivered within 15 days.

Can I have a sample order?

Yes, we welcome sample orders to test and check quality.
