16kwh Home Energy Storage System with Built-in Fan Cooling and 3000W Output Power

16kwh Home Energy Storage System

Built-in Fan Cooling Solar Storage System

3000W Output Power Lithium Battery Storage

Place of Origin:

Changsha, CN

Brand Name:

Ecer

Certification:

Request A Quote

16kwh Home Energy Storage System with Built-in Fan Cooling and 3000W Output Power

Product Details

Model NO.:

SMP-FU002

Power Configuration:

100kW-250kW

Specification:

45cm*67*33

Cooling Method:

Built-in Fan

Battery Pack:

25.6V100Ah

Nominal Voltage:

25.6V

Operating Voltage:

21.6V~28.8V

Rated Energy:

2.56kWh

PV Voltage:

160VDC

MPPT Voltage:

30~128VDC

Input Power:

1600W

Charge/Discharge Current:

50A

Output Voltage:

220~240VAC

Output Current:

17A (terminal)/10A (socket)

Rated Output Power:

3000W

Highlight:

16kwh Home Energy Storage System

Built-in Fan Cooling Solar Storage System

3000W Output Power Lithium Battery Storage

Payment & Shipping Terms

Minimum Order Quantity

Price

1299

Related Products

Contact Now

Product Description

Advanced 16kWh Home Battery for Durable Energy Storage Solutions

PV Energy Storage Integrated Machine

The H3 series solar storage system merges photovoltaic inverters with lithium batteries, simplifying wiring and maintenance. It ensures 24-hour outdoor power, perfect for areas without electricity.

Product Specifications

Model	SMP-FU002
Battery Pack Specifications	25.6V100Ah
Nominal Voltage	25.6V
Operating Voltage Range	21.6V~28.8V
Rated Energy	2.56kWh
Maximum PV Open-Circuit Voltage	160VDC
MPPT Voltage Range	30~128VDC
Maximum Input Power	1600W
Maximum Charge/Discharge Current	50A
Input/Output Voltage	220~240VAC
Selectable Voltage Range	170V~280VAC(UPS)/90V~280VAC(APL)/184V~253VAC(VDE)
Input Current	14A
Output Current	17A (terminal)/10A (socket)
Frequency	50Hz/60Hz (adaptive)
Rated Output Power	3000W
Communication Protocol	RS485/WIFI
Operating Altitude	≤2000m
Cooling Method	Built-in Fan
Installation Type	Floor-standing
IP Rating	IP20
Cycle Life	≥6000 @25℃,80%DOD
Operating Temperature	0~55℃
Storage Temperature	-20~55℃
Humidity	≤80%
Product Dimensions	450671330mm
Packaging Dimensions	550771450mm
Net Weight	45kg

Manufacturer Profile

Zhejiang Fimos Energy Technology Co., Ltd.

Zhejiang Fimos Energy Technology Co., Ltd. is a forward-thinking enterprise in advanced energy storage solutions. Focusing on innovation and sustainability, we empower a greener future with safe, efficient, and intelligent energy systems for residential, commercial, and mobile use.
