Feimengsi Hybrid Inverter with Ultra-wide MPPT Range Pure Sine Wave Output and Bidirectional Design for Solar and Mains Charging

Ultra-wide MPPT range Hybrid Inverter

Pure Sine Wave Output Energy Storage Inverter

Bidirectional Design Hybrid Inverter

Place of Origin:

Changsha, CN

Brand Name:

Ecer

Certification:

Request A Quote

Feimengsi Hybrid Inverter with Ultra-wide MPPT Range Pure Sine Wave Output and Bidirectional Design for Solar and Mains Charging

Product Details

Output Power:

>1000W

Power Source:

Solar Power, Wind Power

Circuit Topologies:

Push-pull Type

Rated Power:

1000W| 1300W| 1800W| 1800w| 2300W| 3300W

Max PV Input Power:

1500W| 2000W| 2500W| 2500W| 3000W| 5000W

MPPT Tracking Voltage Range:

30Vdc-240Vdc| 40Vdc-350Vdc| 40Vdc-450Vdc

Rated Voltage:

180Vdc| 240Vdc

Max PV Input Voltage:

300Vdc| 400Vdc| 500Vdc

Max PV Input Current:

13A| 15A| 18A

Battery Type:

Lead-acid Battery/Lithium Battery

Rated Battery Voltage:

12Vdc| 24Vdc

Battery Voltage Range:

10.5-15Vdc(default)| 21-30Vdc(default)

Max PV Charging Current:

60A| 80A| 100A| 60A| 80A| 120A

Max AC Charging Current:

40A| 50A| 65A| 35A| 50A| 80A

Output Wave:

Pure Sine Wave

Highlight:

Ultra-wide MPPT range Hybrid Inverter

Pure Sine Wave Output Energy Storage Inverter

Bidirectional Design Hybrid Inverter

Payment & Shipping Terms

Minimum Order Quantity

Price

180

Related Products

Contact Now

Product Description

Feimengsi Hybrid Inverter - Advanced Energy Storage Solutions

Reliable Wall-Mounted Home Battery Storage System

High-frequency design with exceptional power density, compact size, and superior efficiency. Features bidirectional design for both solar and mains charging with ultra-wide MPPT range from 30Vdc to 80Vdc.

Key Features

Configurable operation modes (grid-connected, off-grid, hybrid)
Grid-connected current settings capability
Output and charging priority settings
BMS communication support for lithium batteries
Battery-free operation support
Compatible with lead-acid and lithium batteries
Customizable battery parameters via operation panel

Technical Specifications

Specification	1000W	1300W	1800W	1800w	2300W	3300W
Rated Power	1000W	1300W	1800W	1800w	2300W	3300W
Max PV Input Power	1500W	2000W	2500W	2500W	3000W	5000W
MPPT Tracking Voltage Range	30Vdc-240Vdc		40Vdc-350Vdc		40Vdc-450Vdc
Rated Voltage	180Vdc			240Vdc
Max PV Input Voltage (VOC)	300Vdc		400Vdc		500Vdc
Max PV Input Current	13A	15A	18A	-	-	-
Battery Type	Lead-acid Battery/Lithium Battery
Rated Battery Voltage	12Vdc			24Vdc
Max PV Charging Current	60A	80A	100A	60A	80A	120A
Max AC Charging Current	40A	50A	65A	35A	50A	80A
Output Current	4.3A	5.6A	7.8A	7.8A	10A	14.3A
