16kWh All-in-One Residential Battery for 24-hour Outdoor Power Home Energy Storage System

16kWh Residential Battery

All-in-One Home Energy Storage System

24-hour Outdoor Power Lithium Battery Storage

Place of Origin:

Changsha, CN

Brand Name:

Ecer

Certification:

Request A Quote

16kWh All-in-One Residential Battery for 24-hour Outdoor Power Home Energy Storage System

Product Details

Model:

SMP-FU002

Battery Pack:

25.6V100Ah

Nominal Voltage:

25.6V

Operating Voltage:

21.6V~28.8V

Rated Energy:

2.56kWh

Max PV Voltage:

160VDC

MPPT Voltage:

30~128VDC

Max Input Power:

1600W

Max Current:

50A

Input/Output Voltage:

220~240VAC

Output Current:

17A (terminal)/10A (socket)

Rated Output Power:

3000W

Cycle Life:

≥6000 @25℃,80%DOD

Product Dimensions:

450*671*330mm

Net Weight:

45kg

Highlight:

16kWh Residential Battery

All-in-One Home Energy Storage System

24-hour Outdoor Power Lithium Battery Storage

Payment & Shipping Terms

Minimum Order Quantity

Price

1299

Related Products

Contact Now

Product Description

High-Capacity 16kwh Residential Battery for All-in-One Energy Storage

PV Energy Storage Integrated Machine

The H3 series combines photovoltaic inverters and lithium batteries, reducing wiring complexity and simplifying maintenance. This integrated solution ensures 24-hour outdoor power availability, making it ideal for electricity-scarce areas.

Technical Specifications

Product Model
Model	SMP-FU002

Battery Pack Specifications

Battery Pack Specifications	25.6V100Ah
Nominal Voltage	25.6V
Operating Voltage Range	21.6V~28.8V
Rated Energy	2.56kWh

PV Input Parameters

Maximum PV Open-Circuit Voltage	160VDC
MPPT Voltage Range	30~128VDC
Maximum Input Power	1600W
Maximum Charge/Discharge Current	50A

AC Output/Input Parameters

Input/Output Voltage	220~240VAC
Selectable Voltage Range	170V~280VAC(UPS)/90V~280VAC(APL)/184V~253VAC(VDE)
Input Current	14A
Output Current	17A (terminal)/10A (socket)
Frequency	50Hz/60Hz (adaptive)
Rated Output Power	3000W

General Parameters

Communication Protocol	RS485/WIFI
Operating Altitude	≤2000m
Cooling Method	Built-in Fan
Installation Type	Floor-standing
IP Rating	IP20
Cycle Life	≥6000 @25℃,80%DOD
Operating Temperature	0~55℃
Storage Temperature	-20~55℃
Humidity	≤80%
Product Dimensions	450671330mm
Packaging Dimensions	550771450mm
Net Weight	45kg
