Name: Efficient Feimengsi Hybrid Inverter with Bidirectional Design and Ultra-Wide MPPT Range for Pure Sine Wave Output
Brand: test
Price: 180 USD
Availability: InStock

Home > Products > Energy >

Efficient Feimengsi Hybrid Inverter with Bidirectional Design and Ultra-Wide MPPT Range for Pure Sine Wave Output

Bidirectional Design Hybrid Inverter

Ultra-Wide MPPT Range Energy Storage System

Pure Sine Wave Output Home Battery Storage

Place of Origin:

Changsha, CN

Brand Name:

Ecer

Certification:

Request A Quote

Efficient Feimengsi Hybrid Inverter with Bidirectional Design and Ultra-Wide MPPT Range for Pure Sine Wave Output

Product Details

Rated Power:

1000W|1300W|1800W|1800w|2300W|3300W

Max PV Input Power:

1500W|2000W|2500W|2500W|3000W|5000W

MPPT Voltage Range:

30Vdc-240Vdc|40Vdc-350Vdc|40Vdc-450Vdc

Rated Voltage:

180Vdc|240Vdc

Max PV Voltage:

300Vdc|400Vdc|500Vdc

Max PV Current:

13A|15A|18A

MPPT Channels:

1 Routed

Battery Type:

Lead-acid Battery/Lithium Battery

Rated Battery Voltage:

12Vdc|24Vdc

Battery Voltage Range:

10.5-15Vdc(default)|21-30Vdc(default)

Max PV Charging Current:

60A|80A|100A|60A|80A|120A

Max AC Charging Current:

40A|50A|65A|35A|50A|80A

Rated Input Voltage:

230V(220V Or240V Can Be Set)

Input Voltage Range:

165Vac-280Vac/120Vac~280Vac (Can Be Set)

Output Voltage Accuracy:

±2%

Highlight:

Bidirectional Design Hybrid Inverter

Ultra-Wide MPPT Range Energy Storage System

Pure Sine Wave Output Home Battery Storage

Payment & Shipping Terms

Minimum Order Quantity

Price

180

Related Products

Contact Now

Product Description

Efficient Feimengsi Hybrid Inverter - Power Your Home Sustainably

Reliable Wall-Mounted Home Battery Storage System

High-frequency, high power density, compact size, and high efficiency bidirectional design for solar and mains charging with ultra-wide MPPT range (30Vdc to 80Vdc).

Detailed Specifications

Specification	1000W	1300W	1800W	1800w	2300W	3300W
Rated Power	1000W	1300W	1800W	1800w	2300W	3300W
Max PV Input Power	1500W	2000W	2500W	2500W	3000W	5000W
MPPT Tracking Voltage Range	30Vdc-240Vdc		40Vdc-350Vdc		40Vdc-450Vdc
Rated Voltage	180Vdc			240Vdc
Max PV Input Voltage (VOC)	300Vdc		400Vdc		500Vdc
Max PV Input Current	13A	15A	18A	-	-	-
MPPT Tracking Channels	1 Routed
Battery Type	Lead-acid Battery/Lithium Battery (Customized batteries can be set with different types of charge and discharge parameters through the operation panel)
Rated Battery Voltage	12Vdc			24Vdc
Battery Voltage Range	10.5-15Vdc (default)			21-30Vdc (default)

Advanced Features

Supports grid-connected, off-grid, and hybrid modes with grid-connected current settings

Offers output and charging priority settings with BMS communication support for lithium batteries

Enables battery-free operation mode for flexible power management

Technical Specifications

MPPT Tracking Efficiency: ≥99.9%

Transfer Time: 10ms (Typical value)

Display: LCD+LED

Cooling Method: Cooling fan in intelligent control

Communication: RS485/Mobile APP (WIFI Monitoring or GPRS monitoring - Optional)

Protection Degree: IP20

Anti-islanding protection: ≤2S

Frequently Asked Questions

Why choose us?

Years in electrical production, professional sales & R&D, competitive pricing, timely delivery, sincere service

How is your after-sale service?

1-2 years warranty, 1% spare parts free, PCB repair or replacement

What certifications do you have?

ISO9001, ISO14001, CE, ROHS, UL, etc. Products pass various labor tests as per country requirements.

Delivery time:

Standard products delivered within 15 days

Can I have a sample order?

Yes, sample orders are welcome for quality testing
