Name: 200V High Voltage Home Energy Storage System with 5.12kWh Nominal Capacity and Modular Stackable Design
Brand: test
Price: 2509 USD
Availability: InStock

Home > Products > Energy >

200V High Voltage Home Energy Storage System with 5.12kWh Nominal Capacity and Modular Stackable Design

200V High Voltage Home Energy Storage System

5.12kWh Nominal Capacity Solar Power Station

Modular Stackable Design Stacked Energy Storage System

Place of Origin:

Changsha, CN

Brand Name:

Ecer

Certification:

Request A Quote

200V High Voltage Home Energy Storage System with 5.12kWh Nominal Capacity and Modular Stackable Design

Product Details

Nominal Capacity:

5.12kwh

Product Dimensions:

700mm*235mm*307mm

Single Battery Energy:

5.12kWh

Nominal Voltage:

102.4V

Packaging Dimensions:

790*325*402mm

Total Product Dimensions:

700*235*1470mm|700*235*1772mm|700*235*2075mm

Total Product Net Weight:

132kg|177kg|222kg

Total Voltage:

204.8V|307.2V|409.6V

Rated Energy:

10.24kWh|15.36kWh|20.48kWh

Operating Voltage:

172.8~230.4V|259.2~345.5V|345.6~460.8V

Operating Temperature:

0~55°C

Storage Temperature:

-20~55°C

IP Rating:

IP54

Cooling Method:

Natural Cooling

Communication Protocol:

CAN/WIFI

Highlight:

200V High Voltage Home Energy Storage System

5.12kWh Nominal Capacity Solar Power Station

Modular Stackable Design Stacked Energy Storage System

Payment & Shipping Terms

Minimum Order Quantity

Price

2509

Related Products

Contact Now

Product Description

Home Solar Power Station Stacked Energy Storage System

200V High Voltage with Inverter - Advanced energy storage solution for residential applications

Product Gallery

Technical Specifications

Parameter	SMP-CU004-2	SMP-CU004-3	SMP-CU004-4
Battery Pack Parameters
Single Battery Pack Energy	5.12kWh
Nominal Voltage	102.4V
Product Dimensions	700235307mm
Packaging Dimensions	790325402mm
Total Product Dimensions	7002351470mm	7002351772mm	7002352075mm
Total Product Net Weight	132kg	177kg	222kg
Total Voltage	204.8V	307.2V	409.6V
Rated Energy	10.24kWh	15.36kWh	20.48kWh
Operating Voltage	172.8~230.4V	259.2~345.5V	345.6~460.8V
Operating Temperature	0~55°C
Storage Temperature	-20~55°C
IP Rating	IP54
Cooling Method	Natural Cooling
Communication Protocol	CAN/WIFI
PV Input Parameters
Maximum Power	15000W
Maximum Voltage	1000VDC
MPPT Voltage Range	200~850VDC
Maximum Current per String	13A/13A
AC Output/Input Parameters
Standard Power	10000W
Maximum Output/Input Current	17A/25A
Standard Frequency/Voltage	50/60Hz; 400/380VAC

Product Features

Manufacturer Information

Zhejiang Fimos Energy Technology Co., Ltd.

Zhejiang Fimos Energy Technology Co., Ltd. is a forward-thinking enterprise dedicated to the research, development, production, and sales of advanced energy storage solutions. With a strong focus on innovation and sustainability, we aim to empower a greener future by providing safe, efficient, and intelligent energy storage systems for residential, commercial, and mobile applications.

Logistics and Services

Frequently Asked Questions

Q1. Do you have any MOQ limit?

A: Yes. In general, MOQ is 1 pallet.

Q2. How about your delivery time?

A: For the big capacity, we can deliver around 25 days. Depends on the items and the quantity of your order. It usually takes 1-2 days if in stock.

Q3. Can you OEM and ODM Service?

A: Yes, we can provide free OEM Service, and ODM Service. We can design the packaging and logo according to your requirements.

Q4. Do you test all your goods before delivery?

A: Yes, all our products have been tested before delivery.

Q5. Tell me the standard of package?

A: We use cartons and pallets for protection.

Q6. Could you offer Form A or C/O?

A: No problem. We can prepare relative documents to origin affairs office or other office to apply for related certificates for free.
